Raimann ProfiRip KR 310 M

Longitudinal cutting line with two multi rip saws.
Line is dedicated for longitudinal cutting of wooden logs. Every multi rip saw is equipped with one automatic adjustable movable saw. Maximal wood yield and capacity may be reached. Automatic adjustable saw allows adjustment of cutting pattern for every single log.
Line consists of:
1. Multirip saw for first cut Raimann ProfiRip KR 310M No.06323,
2. Connecting transporter ATQL+G 4000 Nr. 06792,
3. Multirip saw for second cut Raimann ProfiRip KR 310M No.06324.

1. Multirip saw for first cut Raimann ProfiRip KR 310M No.06323. This machine performs first cut. Machine is equipped with one automatic adjustable movable saw and two fest standing saws. Log is forwarded via toothed chain, so maximal stability is acquired. Feeding speed with steples adjustment. Cutting path of every caw is displayed via laser.
Parameters of in-feed log:
Max cutting width: 310 mm
Max width of piece (opening): 1150 mm
Thickness: 10 - 115 mm (depends on options)
Min length: 740 mm
Machine dimensions:
Width of feeding chain: 340 mm
Diameter main saw shaft: 65 mm
Diameter saw blade collector: 80 mm
Min diameter saw: 250 mm
Max diameter saw: 380 mm
Rotation main saw shaft: 3900 min-1
Piece feeding speed: 8 – 48 m/min
Working height: 850 mm.
Electricity: 400 V/50 Hz, 3 fazės
Weight of machine: ca. 3800 kg
Dust extraction connection diameter: 300 mm
Dust extraction capacity: 7630 m3/h
Capacity main motor: 22 kW
Height adjustment motor: 0,55 kW
Saw blade adjustment motor: 0,25 kW
Feeding motor: 1,5 kW

2. Connecting transporter ATQL+G 4000 Nr. 06792. This is transporter, which connects first cutting machine with the second one. On this transporter also side waste is separated and removed.

3. Multirip saw for second cut Raimann ProfiRip KR 310MNo.06324. This machine performs the final cut of the log. Machine is equipped with one automatic adjustable movable saw and two fest standing saws. Log is forwarded via toothed chain, so maximal stability is acquired. Feeding speed with steples adjustment. Cutting path of every caw is displayed via laser.
Parameters of in-feed log:
Max cutting width: 310 mm
Max width of piece (opening): 800 mm
Thickness: 10 - 115 mm (depends on options)
Ijdjmxkfmspfx Ad Rebf
Min length: 740 mm
Machine dimensions:
Width of feeding chain: 340 mm
Diameter main saw shaft: 65 mm
Diameter saw blade collector: 80 mm
Min diameter saw: 250 mm
Max diameter saw: 380 mm
Rotation main saw shaft: 3900 min-1
Piece feeding speed: 8 – 48 m/min
Working height: 850 mm.
Electricity: 400 V/50 Hz, 3 fazės
Weight of machine: ca. 3800 kg
Dust extraction connection diameter: 300 mm
Dust extraction capacity: 7630 m3/h
Capacity main motor: 22 kW
Height adjustment motor: 0,55 kW
Saw blade adjustment motor: 0,25 kW
Feeding motor: 1,5 kW

Line meets EU safety regulations CE, year 2007.
All 3 machines can be sold separately.
Producer German company RAIMANN, WEINIG Gruppe.

Stil connected.
No guaranty will be issued to the line.
